KSSM autogenerated report

Generated on: 2025-03-30T17:57:29.499728+00:00

Parameters

input file
simulation time: 60 s
time resolution: 1000 µs

Nodes

Node ID	Long Name	Position	Tx Power	Noise Level	Frequency	Lora Mode	Hop Start	Role	Position Interval	Nodeinfo Interval	Text Message Min Interval	Text Message Max Interval	Debug
0xeacb7fe3	Node 1	[2246.37, 57.61, 10]	22	-102	869525000	LongFast	3	CLIENT	0	0	0	10	False
0x30e6712a	Node 2	[2068.78, 2358.12, 10]	22	-102	869525000	LongFast	3	CLIENT	0	0	0	10	False
0x2e051f42	Node 3	[879.1, 298.06, 10]	22	-102	869525000	LongFast	3	CLIENT	0	0	0	10	False
0x4ea75933	Node 4	[-427.16, -526.41, 10]	22	-102	869525000	LongFast	3	CLIENT	0	0	0	10	False
0x115c9cd4	Node 5	[-341.62, 11158.69, 10]	22	-102	869525000	LongFast	3	CLIENT	0	0	0	10	False
0x69ab06d	Node 6	[13.88, 9541.97, 10]	22	-102	869525000	LongFast	3	CLIENT	0	0	0	10	False
0x7ba58adc	Node 7	[2692.67, 12352.01, 10]	22	-102	869525000	LongFast	3	CLIENT	0	0	0	10	False
0xe38f9c97	Node 8	[383.64, 12532.38, 10]	22	-102	869525000	LongFast	3	CLIENT	0	0	0	10	False
0x7f6d214c	Node 9	[12059.18, 933.99, 10]	22	-102	869525000	LongFast	3	CLIENT	0	0	0	10	False
0xed01221f	Node 10	[9625.26, 1928.17, 10]	22	-102	869525000	LongFast	3	CLIENT	0	0	0	10	False
0x86027fba	Node 11	[12313.24, 2848.48, 10]	22	-102	869525000	LongFast	3	CLIENT	0	0	0	10	False
0xf36a53d	Node 12	[9266.98, -930.16, 10]	22	-102	869525000	LongFast	3	CLIENT	0	0	0	10	False
0xc7919207	Node 13	[11381.97, 11590.35, 10]	22	-102	869525000	LongFast	3	CLIENT	0	0	0	10	False
0xfc7f2ee2	Node 14	[9488.55, 9911.11, 10]	22	-102	869525000	LongFast	3	CLIENT	0	0	0	10	False
0xebc7cf59	Node 15	[12198.72, 9912.32, 10]	22	-102	869525000	LongFast	3	CLIENT	0	0	0	10	False
0xaa8abc52	Node 16	[10190.47, 12933.95, 10]	22	-102	869525000	LongFast	3	CLIENT	0	0	0	10	False
0xfeea9ca5	Node 17	[8000.0, 6000.0, 10]	22	-102	869525000	LongFast	3	CLIENT	0	0	0	10	False
0x70b13ce3	Node 18	[5000.0, 7732.05, 10]	22	-102	869525000	LongFast	3	CLIENT	0	0	0	10	False
0xcae20eaf	Node 19	[5000.0, 4267.95, 10]	22	-102	869525000	LongFast	3	CLIENT	0	0	0	10	False

Results

node_id	time	long_name	role	position	tx_power	noise_level	frequency	lora_mode	state	backoff_time	message_queue_len	messages_heard	known_nodes	rx_success	rx_fail	rx_dups	rx_unicast	tx_done	forwarded	tx_cancelled	collisions_caused	tx_origin	messages_confirmed	tx_sime_sum	rx_time_sum	backoff_time_sum	tx_util	air_util
069ab06d	59773000	Node 6	Role.CLIENT	[13.88, 9541.97, 10]	22	-102	869525000	LoRaMode.LONG_FAST	RX_BUSY	100560.0	17	40	11	79	12	32	0	12	23	7	4	9	32	3928000	28188000	20824000	0.0657	0.5373
0f36a53d	59893000	Node 12	Role.CLIENT	[9266.98, -930.16, 10]	22	-102	869525000	LoRaMode.LONG_FAST	WAITING_TO_TX	421680.0	2	32	8	56	1	18	0	35	31	5	23	14	25	11129000	17724000	23256000	0.1858	0.4817
115c9cd4	59773000	Node 5	Role.CLIENT	[-341.62, 11158.69, 10]	22	-102	869525000	LoRaMode.LONG_FAST	RX_BUSY	472160.0	9	36	11	69	10	22	0	23	27	13	16	12	43	7530000	24597000	21798000	0.1260	0.5375
2e051f42	59726000	Node 3	Role.CLIENT	[879.1, 298.06, 10]	22	-102	869525000	LoRaMode.LONG_FAST	WAITING_TO_TX	1698760.0	11	32	12	66	16	27	0	20	23	4	18	11	25	6365000	25450000	23179000	0.1066	0.5327
30e6712a	59773000	Node 2	Role.CLIENT	[2068.78, 2358.12, 10]	22	-102	869525000	LoRaMode.LONG_FAST	RX_BUSY	516600.0	18	32	12	54	53	16	0	20	19	2	14	14	41	6553000	29741000	20655000	0.1096	0.6072
4ea75933	59726000	Node 4	Role.CLIENT	[-427.16, -526.41, 10]	22	-102	869525000	LoRaMode.LONG_FAST	WAITING_TO_TX	1678840.0	8	32	11	53	2	13	0	29	25	3	19	12	18	9336000	17561000	24651000	0.1563	0.4503
70b13ce3	59771000	Node 18	Role.CLIENT	[5000.0, 7732.05, 10]	22	-102	869525000	LoRaMode.LONG_FAST	TX_BUSY	0.0	11	28	13	34	105	4	0	24	19	0	36	8	38	7727000	34099000	15847000	0.1293	0.6998
7ba58adc	59773000	Node 7	Role.CLIENT	[2692.67, 12352.01, 10]	22	-102	869525000	LoRaMode.LONG_FAST	RX_BUSY	446800.0	7	37	11	67	11	22	0	25	29	7	11	10	29	8099000	24034000	23685000	0.1355	0.5376
7f6d214c	59894000	Node 9	Role.CLIENT	[12059.18, 933.99, 10]	22	-102	869525000	LoRaMode.LONG_FAST	WAITING_TO_TX	444680.0	6	29	8	67	32	28	0	14	23	6	13	10	31	4377000	28344000	23470000	0.0731	0.5463
86027fba	59893000	Node 11	Role.CLIENT	[12313.24, 2848.48, 10]	22	-102	869525000	LoRaMode.LONG_FAST	WAITING_TO_TX	517800.0	5	29	8	56	32	16	0	25	25	6	14	12	33	7836000	24896000	22664000	0.1308	0.5465
aa8abc52	59849000	Node 16	Role.CLIENT	[10190.47, 12933.95, 10]	22	-102	869525000	LoRaMode.LONG_FAST	TX_BUSY	0.0	5	31	12	51	2	13	0	31	25	3	16	14	29	10334000	16889000	27180000	0.1727	0.4549
c7919207	59851000	Node 13	Role.CLIENT	[11381.97, 11590.35, 10]	22	-102	869525000	LoRaMode.LONG_FAST	RX_BUSY	226080.0	16	35	12	79	10	30	0	15	23	6	13	12	44	4921000	28383000	22957000	0.0822	0.5564
cae20eaf	59772000	Node 19	Role.CLIENT	[5000.0, 4267.95, 10]	22	-102	869525000	LoRaMode.LONG_FAST	RX_BUSY	257800.0	9	24	12	39	78	10	0	19	17	1	42	11	36	6288000	30616000	19858000	0.1052	0.6174
e38f9c97	59575000	Node 8	Role.CLIENT	[383.64, 12532.38, 10]	22	-102	869525000	LoRaMode.LONG_FAST	WAITING_TO_TX	1600560.0	9	34	8	58	2	19	0	19	27	2	15	11	25	6076000	19128000	28646000	0.1020	0.4231
eacb7fe3	59727000	Node 1	Role.CLIENT	[2246.37, 57.61, 10]	22	-102	869525000	LoRaMode.LONG_FAST	WAITING_TO_TX	966800.0	13	34	12	71	17	30	0	15	24	9	6	11	22	4978000	26836000	23983000	0.0833	0.5327
ebc7cf59	59851000	Node 15	Role.CLIENT	[12198.72, 9912.32, 10]	22	-102	869525000	LoRaMode.LONG_FAST	RX_BUSY	880200.0	13	37	12	75	11	32	0	19	27	6	11	10	19	6256000	27056000	24248000	0.1045	0.5566
ed01221f	59894000	Node 10	Role.CLIENT	[9625.26, 1928.17, 10]	22	-102	869525000	LoRaMode.LONG_FAST	WAITING_TO_TX	449280.0	8	29	8	52	61	17	0	18	22	3	24	10	26	5853000	30731000	20299000	0.0977	0.6108
fc7f2ee2	59851000	Node 14	Role.CLIENT	[9488.55, 9911.11, 10]	22	-102	869525000	LoRaMode.LONG_FAST	RX_BUSY	779720.0	20	39	13	65	45	21	0	19	23	5	12	12	40	6142000	31056000	21352000	0.1026	0.6215
feea9ca5	59773000	Node 17	Role.CLIENT	[8000.0, 6000.0, 10]	22	-102	869525000	LoRaMode.LONG_FAST	RX_BUSY	1430440.0	3	15	10	21	131	4	0	21	14	1	48	11	49	6704000	35213000	15849000	0.1122	0.7013
