KSSM autogenerated report

Generated on: 2025-03-31T07:03:13.332507+00:00

Parameters

input file
simulation time: 60 s
time resolution: 1000 µs

Nodes

Node ID	Long Name	Position	Tx Power	Noise Level	Frequency	Lora Mode	Hop Start	Role	Position Interval	Nodeinfo Interval	Text Message Min Interval	Text Message Max Interval	Debug
0xeacb7fe3	Node 1	[2246.37, 57.61, 10]	22	-102	869525000	MediumFast	3	CLIENT	0	0	0	10	False
0x30e6712a	Node 2	[2068.78, 2358.12, 10]	22	-102	869525000	MediumFast	3	CLIENT	0	0	0	10	False
0x2e051f42	Node 3	[879.1, 298.06, 10]	22	-102	869525000	MediumFast	3	CLIENT	0	0	0	10	False
0x4ea75933	Node 4	[-427.16, -526.41, 10]	22	-102	869525000	MediumFast	3	CLIENT	0	0	0	10	False
0x115c9cd4	Node 5	[-341.62, 11158.69, 10]	22	-102	869525000	MediumFast	3	CLIENT	0	0	0	10	False
0x69ab06d	Node 6	[13.88, 9541.97, 10]	22	-102	869525000	MediumFast	3	CLIENT	0	0	0	10	False
0x7ba58adc	Node 7	[2692.67, 12352.01, 10]	22	-102	869525000	MediumFast	3	CLIENT	0	0	0	10	False
0xe38f9c97	Node 8	[383.64, 12532.38, 10]	22	-102	869525000	MediumFast	3	CLIENT	0	0	0	10	False
0x7f6d214c	Node 9	[12059.18, 933.99, 10]	22	-102	869525000	MediumFast	3	CLIENT	0	0	0	10	False
0xed01221f	Node 10	[9625.26, 1928.17, 10]	22	-102	869525000	MediumFast	3	CLIENT	0	0	0	10	False
0x86027fba	Node 11	[12313.24, 2848.48, 10]	22	-102	869525000	MediumFast	3	CLIENT	0	0	0	10	False
0xf36a53d	Node 12	[9266.98, -930.16, 10]	22	-102	869525000	MediumFast	3	CLIENT	0	0	0	10	False
0xc7919207	Node 13	[11381.97, 11590.35, 10]	22	-102	869525000	MediumFast	3	CLIENT	0	0	0	10	False
0xfc7f2ee2	Node 14	[9488.55, 9911.11, 10]	22	-102	869525000	MediumFast	3	CLIENT	0	0	0	10	False
0xebc7cf59	Node 15	[12198.72, 9912.32, 10]	22	-102	869525000	MediumFast	3	CLIENT	0	0	0	10	False
0xaa8abc52	Node 16	[10190.47, 12933.95, 10]	22	-102	869525000	MediumFast	3	CLIENT	0	0	0	10	False
0xfeea9ca5	Node 17	[8000.0, 6000.0, 10]	22	-102	869525000	MediumFast	3	CLIENT	0	0	0	10	False
0x70b13ce3	Node 18	[5000.0, 7732.05, 10]	22	-102	869525000	MediumFast	3	CLIENT	0	0	0	10	False
0xcae20eaf	Node 19	[5000.0, 4267.95, 10]	22	-102	869525000	MediumFast	3	CLIENT	0	0	0	10	False

Results

node_id	time	long_name	role	position	tx_power	noise_level	frequency	lora_mode	state	backoff_time	message_queue_len	messages_heard	known_nodes	rx_success	rx_fail	rx_dups	rx_unicast	tx_done	forwarded	tx_cancelled	collisions_caused	tx_origin	messages_confirmed	tx_sime_sum	rx_time_sum	backoff_time_sum	tx_util	air_util
069ab06d	59979000	Node 6	Role.CLIENT	[13.88, 9541.97, 10]	22	-102	869525000	LoRaMode.MEDIUM_FAST	TX_BUSY	0.0	0	34	4	65	5	20	0	26	34	19	0	12	33	2300000	5632000	9816000	0.0383	0.1322
0f36a53d	59948000	Node 12	Role.CLIENT	[9266.98, -930.16, 10]	22	-102	869525000	LoRaMode.MEDIUM_FAST	IDLE	0.0	0	61	11	85	2	16	0	53	50	6	28	10	28	4657000	7338000	16214000	0.0777	0.2001
115c9cd4	59981000	Node 5	Role.CLIENT	[-341.62, 11158.69, 10]	22	-102	869525000	LoRaMode.MEDIUM_FAST	RX_BUSY	0.0	0	35	4	70	2	25	0	22	35	20	4	10	30	1860000	6064000	11211000	0.0310	0.1321
2e051f42	59941000	Node 3	Role.CLIENT	[879.1, 298.06, 10]	22	-102	869525000	LoRaMode.MEDIUM_FAST	WAITING_TO_TX	203520.0	0	62	9	122	0	45	0	26	52	34	5	12	49	2222000	10390000	16960000	0.0371	0.2104
30e6712a	59941000	Node 2	Role.CLIENT	[2068.78, 2358.12, 10]	22	-102	869525000	LoRaMode.MEDIUM_FAST	WAITING_TO_TX	457920.0	0	66	13	116	34	40	0	58	62	12	8	11	70	4972000	11942000	18384000	0.0829	0.2822
4ea75933	59941000	Node 4	Role.CLIENT	[-427.16, -526.41, 10]	22	-102	869525000	LoRaMode.MEDIUM_FAST	WAITING_TO_TX	228960.0	0	62	9	111	0	33	0	37	52	21	1	12	53	3177000	9446000	16419000	0.0530	0.2106
70b13ce3	59683000	Node 18	Role.CLIENT	[5000.0, 7732.05, 10]	22	-102	869525000	LoRaMode.MEDIUM_FAST	IDLE	0.0	0	70	15	119	2	30	0	59	64	17	16	13	104	5195000	10204000	19950000	0.0870	0.2580
7ba58adc	59980000	Node 7	Role.CLIENT	[2692.67, 12352.01, 10]	22	-102	869525000	LoRaMode.MEDIUM_FAST	RX_BUSY	0.0	0	33	4	63	3	18	0	29	33	16	2	12	36	2483000	5452000	9641000	0.0414	0.1323
7f6d214c	59953000	Node 9	Role.CLIENT	[12059.18, 933.99, 10]	22	-102	869525000	LoRaMode.MEDIUM_FAST	WAITING_TO_TX	50880.0	0	57	11	123	33	49	0	37	46	21	0	13	48	3195000	12536000	15615000	0.0533	0.2624
86027fba	59948000	Node 11	Role.CLIENT	[12313.24, 2848.48, 10]	22	-102	869525000	LoRaMode.MEDIUM_FAST	IDLE	0.0	0	59	11	85	2	17	0	53	48	8	16	13	52	4635000	7338000	18832000	0.0773	0.1997
aa8abc52	59200000	Node 16	Role.CLIENT	[10190.47, 12933.95, 10]	22	-102	869525000	LoRaMode.MEDIUM_FAST	IDLE	0.0	0	66	11	113	0	37	0	34	55	29	5	9	41	2924000	9694000	15477000	0.0494	0.2131
c7919207	59201000	Node 13	Role.CLIENT	[11381.97, 11590.35, 10]	22	-102	869525000	LoRaMode.MEDIUM_FAST	IDLE	0.0	0	62	11	125	0	46	0	22	51	41	4	13	52	1908000	10698000	14876000	0.0322	0.2129
cae20eaf	59822000	Node 19	Role.CLIENT	[5000.0, 4267.95, 10]	22	-102	869525000	LoRaMode.MEDIUM_FAST	WAITING_TO_TX	212120.0	1	75	15	139	38	48	0	60	70	17	18	9	80	5214000	14371000	20158000	0.0872	0.3274
e38f9c97	59980000	Node 8	Role.CLIENT	[383.64, 12532.38, 10]	22	-102	869525000	LoRaMode.MEDIUM_FAST	RX_BUSY	0.0	0	33	4	72	5	27	0	19	33	23	0	12	36	1601000	6325000	9507000	0.0267	0.1321
eacb7fe3	59941000	Node 1	Role.CLIENT	[2246.37, 57.61, 10]	22	-102	869525000	LoRaMode.MEDIUM_FAST	IDLE	0.0	0	62	9	121	0	44	0	27	52	34	6	12	43	2363000	10250000	16813000	0.0394	0.2104
ebc7cf59	59200000	Node 15	Role.CLIENT	[12198.72, 9912.32, 10]	22	-102	869525000	LoRaMode.MEDIUM_FAST	IDLE	0.0	0	65	11	115	0	37	0	32	54	31	3	10	43	2832000	9784000	16300000	0.0478	0.2131
ed01221f	59948000	Node 10	Role.CLIENT	[9625.26, 1928.17, 10]	22	-102	869525000	LoRaMode.MEDIUM_FAST	IDLE	0.0	0	53	12	116	88	43	0	50	52	15	17	15	126	4308000	15301000	16819000	0.0719	0.3271
fc7f2ee2	59200000	Node 14	Role.CLIENT	[9488.55, 9911.11, 10]	22	-102	869525000	LoRaMode.MEDIUM_FAST	IDLE	0.0	0	64	12	110	40	35	0	59	63	14	15	12	82	5067000	11906000	19649000	0.0856	0.2867
feea9ca5	59948000	Node 17	Role.CLIENT	[8000.0, 6000.0, 10]	22	-102	869525000	LoRaMode.MEDIUM_FAST	WAITING_TO_TX	356160.0	0	68	15	137	91	54	0	62	63	10	32	10	80	5364000	17347000	19055000	0.0895	0.3788
