KSSM autogenerated report

Generated on: 2025-03-30T18:34:47.043877+00:00

Parameters

input file
simulation time: 60 s
time resolution: 1000 µs

Nodes

Node ID	Long Name	Position	Tx Power	Noise Level	Frequency	Lora Mode	Hop Start	Role	Position Interval	Nodeinfo Interval	Text Message Min Interval	Text Message Max Interval	Debug
0xdeadbeef	Node 1	[1000, 1000, 10]	22	-100	869525000	LongFast	3	CLIENT	0	0	0	15	False
0xcafebabe	Node 2	[1000, 4000, 10]	22	-100	869525000	LongFast	3	CLIENT	0	0	0	15	False
0xfafac0c0	Node 3	[1000, 7000, 10]	22	-100	869525000	LongFast	3	CLIENT	0	0	0	15	False
0x0000aaaa	Node 4	[4000, 1000, 10]	22	-100	869525000	LongFast	3	CLIENT	0	0	0	15	False
0xbaab1234	Node 5	[4000, 4000, 10]	22	-100	869525000	LongFast	3	CLIENT	0	0	0	15	False
0x12345678	Node 6	[4000, 7000, 10]	22	-100	869525000	LongFast	3	CLIENT	0	0	0	15	False
0xabcdef00	Node 7	[7000, 1000, 10]	22	-100	869525000	LongFast	3	CLIENT	0	0	0	15	False
0x3ab02511	Node 8	[7000, 4000, 10]	22	-100	869525000	LongFast	3	CLIENT	0	0	0	15	False
0xefeebaac	Node 9	[7000, 7000, 10]	22	-100	869525000	LongFast	3	CLIENT	0	0	0	15	False

Results

node_id	time	long_name	role	position	tx_power	noise_level	frequency	lora_mode	state	backoff_time	message_queue_len	messages_heard	known_nodes	rx_success	rx_fail	rx_dups	rx_unicast	tx_done	forwarded	tx_cancelled	collisions_caused	tx_origin	messages_confirmed	tx_sime_sum	rx_time_sum	backoff_time_sum	tx_util	air_util
0000aaaa	59654000	Node 4	Role.CLIENT	[4000, 1000, 10]	22	-100	869525000	LoRaMode.LONG_FAST	WAITING_TO_TX	398680.0	2	19	9	32	83	6	0	23	18	0	42	8	33	7217000	28918000	17779000	0.1210	0.6057
12345678	59866000	Node 6	Role.CLIENT	[4000, 7000, 10]	22	-100	869525000	LoRaMode.LONG_FAST	TX_BUSY	0.0	2	19	8	45	68	16	0	23	18	0	29	8	37	7135000	29976000	13520000	0.1192	0.6199
3ab02511	59867000	Node 8	Role.CLIENT	[7000, 4000, 10]	22	-100	869525000	LoRaMode.LONG_FAST	RX_BUSY	0.0	0	19	9	38	84	13	0	20	17	3	25	8	31	6300000	31206000	16051000	0.1052	0.6265
abcdef00	59654000	Node 7	Role.CLIENT	[7000, 1000, 10]	22	-100	869525000	LoRaMode.LONG_FAST	WAITING_TO_TX	477360.0	1	33	9	51	0	15	0	33	31	4	47	7	8	10576000	15870000	23083000	0.1773	0.4433
baab1234	59868000	Node 5	Role.CLIENT	[4000, 4000, 10]	22	-100	869525000	LoRaMode.LONG_FAST	RX_BUSY	274840.0	9	12	6	13	205	0	0	9	7	0	0	7	24	2685000	44677000	9276000	0.0448	0.7911
cafebabe	59868000	Node 2	Role.CLIENT	[1000, 4000, 10]	22	-100	869525000	LoRaMode.LONG_FAST	RX_BUSY	161680.0	4	22	9	37	84	13	0	19	16	0	27	9	32	5961000	31422000	16502000	0.0996	0.6244
deadbeef	59511000	Node 1	Role.CLIENT	[1000, 1000, 10]	22	-100	869525000	LoRaMode.LONG_FAST	IDLE	0.0	0	29	9	51	0	19	0	34	27	0	57	7	8	10612000	15812000	18744000	0.1783	0.4440
efeebaac	59867000	Node 9	Role.CLIENT	[7000, 7000, 10]	22	-100	869525000	LoRaMode.LONG_FAST	RX_BUSY	0.0	0	27	9	51	1	15	0	34	27	1	44	9	29	10840000	15792000	21330000	0.1811	0.4449
fafac0c0	59868000	Node 3	Role.CLIENT	[1000, 7000, 10]	22	-100	869525000	LoRaMode.LONG_FAST	RX_BUSY	557560.0	0	29	9	51	0	20	0	32	27	1	47	7	7	10263000	15730000	19217000	0.1714	0.4342
